LQP type lateral shake enclosed screw hoist
Number of hits：27372015-10-28 16:27:52 Source: http://www.xhshuixing.com/
feature：
1.It can be applied to farmland irrigation and small flood prevention and drainage project.
2.It has self-locking function in order to stop at any positions.
3.Full closed hoist and not limited to geographic position
4.It is equipped with special anti-theft wrench and has the function of anti-theft water.
5.Crack can be poured into cement and has the function of anti-theft.
6 It could be opened and closed flexibly and has long service life. It needs no maintenance within 30 years.
参数/
parameter
启闭力/
hoisting capacity
闭门力/
closing force
升降高度/
lifting height
螺杆直径/
Screw rod diameter
a
c
L1
L2
L3
h1
h2
h3
d1
d2
d3
d4
b
Hmax
地脚螺栓
型号/
model
KN
KN
QL-0.5
5
2.5
由 客 户提 供/
provided by user
Ø30
130
165
280
150
130
120
30
80
160
Ø48
Ø14
83
16
由升降高度确定
4-M12×200
QL-1
10
5
Ø32
130
165
280
150
130
120
30
80
160
Ø48
Ø17
83
16
QL-2
20
10
Ø40
145
180
290
160
140
120
30
80
185
Ø63.5
Ø20
89
20
4-M14×200
QL-3
30
15
Ø45
180
220
330
200
180
240
40
100
210
Ø63.5
Ø23
102
25
